Front Terminal Series

FT(Front Terminal) Series batteries are designed for the telecommunications fields. With terminals at the front, these batteries are easy to install and maintained,and save floor space,with long life float service design and high energy density, used in back-up power for communication and UPS system, In order to ensure that the power supply is guaranteed online at all times, essential facilities are backed up with high performances battery systems.the dimensions of the terminals fit in a 19’’ and 23” power cabinet,

Voltage : 12V
Capacity : 50Ah to 200Ah
Designed floating service life: 15 years at 25℃/77°F

Features

● 15 years design life in floating condition at 25 ℃/77°F
● Front access terminal with standard width for 19"and 23" racks or cabinets
● Adopt the front terminal design,be convenient for installation and operation
● Excellent high temperature resistance
● Thick plate design and long-life active material formula,
● Low self-discharge rate,high quality and high reliability
● Excellent deep discharge recovery capability
● Adopt 1# electrolytic lead with a purity of 99.994%
● Adopt special patented alloy formula, the grid has stronger corrosion resistance
● Adopt high temperature and high humidity curing process, the life, capacity and consistency are guaranteed
● Wide operating temperature range from -20℃ to 60℃
● UL, CE, IEC Approved

Applications

● Telecommunication
● UPS
● Control system
● Data Center
● Industrial and commercial energy storage system
● Solar& Wind power system
● Electric Power System(EPS)

General Specifications

Model	Nominal Voltage (V)	Capacity (Ah)	Dimensions（mm/in）				Weight ±3%	Terminal
			Length	Width	Height	Total Height	Weight ±3%	Terminal
			mm	mm	mm	mm	Kg	Type	Position
FT12-50	12	50	277	106	221	221	16	F16	E
FT12-55	12	55	277	106	221	221	17	F16	E
FT12-75	12	75	562	114	189	189	25	F18	E
FT12-90	12	95	390	105	265	265	27	F18	E
FT12-100	12	100	395	110	286	286	32.5	F18	E
FT12-105A	12	105	395	110	286	286	33	F18	E
FT12-110A	12	110	395	110	286	286	33.5	F18	E
FT12-105	12	105	506	110	224	239	31	F18	E
FT12-110	12	110	560	125	228	228	33	F18	E
FT12-120	12	120	551	110	239	239	36	F18	E
FT12-125	12	125	436	108	317	317	38	F18	E
FT12-125A	12	125	550	105	315	315	42	F18	E
FT12-150	12	150	551	110	287	287	50	F18	E
FT12-150A	12	150	551	110	287	287	46	F18	E
FT12-155	12	155	546	125	317	323	50	F18	E
FT12-170	12	170	546	125	317	323	54	F18	E
FT12-180	12	180	546	125	317	323	56	F18	E
FT12-155A	12	155	560	126	280	280	49	F18	E
FT12-200	12	200	546	125	317	323	59	F18	E
FT12-180A	12	180	560	126	316	316	60	F18	E
