GEL Battery Series

GEL Battery Series

KG (PVC+GEL) series batteries are manufactured with nano silica gel technology, and have porous PVC separators and GEL electrolyte inside imported from Germany. the main benefit of GEL battery is suitable for deep cycle application with long service life and for extreme high and low ambient temperature or at atrocious weather, By the high-tech gelled electrolyte, gel battery is completely leak proof and spill proof for easy installation in virtually any position even under water. It eliminates ultra deep discharge and acid stratification damage.

Voltage: 2V, 6V, 12V
Capacity:18Ah to 3000Ah
Designed floating service life: 15 years for capacity 33Ah to 280Ah,20 years for capacity 300Ah to 3000Ah @ 25℃/77°F

Features

● With nano silica gel technology, and porous PVC separators
● Leak proof and spill proof
● High consistency, High Reliability and high quality
● Solid Copper Terminals,Tank formed plates
● Quick recharge ability and superior deep-cycle and float performance
● Long service life and Low self Discharge
● Exceptional deep discharge recovery performance
● Well suited to low temperature applications
● Adopt 1# electrolytic lead with a purity of 99.994%
● Adopt thick plate with special patented alloy formula, the grid has stronger corrosion resistance
● Adopt high temperature and high humidity curing process, the life, capacity and consistency are guaranteed
● Wide operating temperature range(-40℃/-40°F to 65℃/149°F)
● UL, CE, IEC Approved

Applications

● Telecommunication
● UPS
● Control system
● Water pumping
● Power plant
● Solar& Wind power system
● Electric Power System(EPS)
● Electric powered vehicles Golf cars
● Mine and ship equipment

General Specifications

Model Nominal
Voltage
(V)		 Capacity
(Ah)		 Dimensions（mm/in） Weight
±3%		 Terminal
Length Width Height Total Height
mm mm mm mm Kg Type Position
KG6-100 6 100 194 170 205 205 15.8 F16 A
KG6-190 6 190 243 187 253 276 31.5 F19 B
KG6-200 6 200 260 180 245 250 26.5 F19 B
KG6-200A 6 200 321 176 226 229 30 F19 A
KG12-18 12 18 181 77 153 167 5.4 F13 D
KG12-24 12 24 166 175 125 125 7.8 F13 D
KG12-28 12 28 166 175 125 125 8.4 F13 D
KG12-24A 12 24 165 125 162 175 8.8 F13 D
KG12-28A 12 28 165 125 162 175 9.2 F13 D
KG12-33 12 33 195 130 146 158 10.2 F16 C
KG12-40 12 40 197 165 155 170 12.8 F16 D
KG12-55 12 55 229 138 201 215 17.5 F16 C
KG12-65 12 65 350 167 155 179 21.5 F16 C
KG12-70 12 70 260 168 202 215 25 F16 C
KG12-80 12 80 306 169 202 215 28 F19 C
KG12-90 12 90 306 169 202 215 31 F19 C
KG12-100 12 100 330 171 197 215 32 F19 C
KG12-110 12 110 330 171 217 235 33 F19 C
KG12-120 12 120 409 176 205 225 38 F19 C
KG12-134 12 134 342 172 262 280 41 F19 C
KG12-150 12 150 485 172 220 240 45 F19 C
KG12-160 12 160 530 207 204 214 54.5 F19 F
KG12-180 12 180 530 207 204 214 57 F19 F
KG12-200 12 200 522 238 203 221 65 F19 E
KG12-250 12 250 521 269 203 221 75.5 F19 E
FT12-50G 12 50 277 106 221 221 17 F16 E
FT12-75G 12 75 562 114 189 189 26 F16 E
FT12-100G 12 100 506 110 224 239 31 F18 E
FT12-105G 12 105 395 110 271 286 31 F18 E
FT12-150G 12 150 551 110 271 287 46 F18 E
FT12-180G 12 180 546 125 308 323 55 F18 E
FT12-180G(I) 12 180 560 126 280 280 53 F18 E
KG2-100 2 100 171 72 206 209 6 F16 G
KG2-150 2 150 171 102 206 211 8.5 F16 G
KG2-200 2 200 173 109 330 365 14 F20 G
KG2-300 2 300 171 151 330 365 19.5 F20 G
KG2-400 2 400 210 171 330 365 26.5 F20 H
KG2-500 2 500 241 171 330 365 31.5 F20 H
KG2-600 2 600 302 175 330 365 36.5 F20 H
KG2-800 2 800 410 175 330 365 50 F20 I
KG2-1000 2 1000 475 175 330 365 62 F20 I
KG2-1500 2 1500 400 350 345 382 95 F20 J
KG2-2000 2 2000 490 350 345 382 140 F20 K
KG2-3000 2 3000 710 350 345 382 192 F20 K
